- Place of Origin: shandong liangshan
- Brand Name: liangyun
- Model Number: SLY9403GFL
- Weight: 6000.000 kg
10 ton farm trailer
1. Axles usually is 2, 3
2. Brand can be FUWA, BPW, also other brands for selection3. Suspension is usually American style,or german style
4. Support legs also can be selected
5. JinDa will try to satisfy all your requirements
Weight: |
|
|
| Tare Weight | 9000kg--40000kg |
| Loading Capacity | 30T--100T |
| Axle Weight Load | 13T-16T |
Specification: |
| |
| Axle number | 2,3 or 4 |
| Axle Brand | Optional upon choice |
| Suspension | Mechanical suspension Or Air suspension |
| King Pin | 2" or 3.5" traction pin |
| Dimensions (LxWxH) | 10000-20000mm×2500-3200mm x3700-3980mm |
| Support legs | 28T |
| Wheel Rim | 9.00-22.5 Or 8.0-20/8.5-20 |
| Wheelbase | 7180/6680/6260+1310+1310+1310mm |
| Steel Spring | 8/10/12 pieces |
| Drawing | Including | |
| Landing Gear | Manual operating, Heavy duty landing gear (Brand Optional upon chioce) |
| Accessories | Tow standard tool box/four trailer spare wheel carrier |
| Light | Tail lamp with turn signal, brake light & reflector, side lamp etc. |
| Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
Tire: |
|
|
| Tire spe. | 12R22.5 Or11.00R20/12.00R20 Vacuum tire |
| Number of Tire | 8 or 12 or 16 pieces |
| Spare Tire Carriers | 2 pieces |
Frame: |
| |
| Main beam | The height of the beam is 500-550mm; Upper plate:10-20mm;Down plate is 12-24mm;Middle plate is 6-14mm. |
| Trailer body | 5mm steel plate, front and back head made of 6mm steel plate the shape can be column or TV square shape |
Brake: |
|
|
| Brake brand | Optional upon choice |
| Brake Chamber | Six big chamber( Brand Optional upon choice ) |
| Brake system | Dual Line Brake system (ABS Optional upon choice) |
